ZAHLEN

API User Guide

Chapter 16 - SDK Examples

Python | curl | JavaScript

Version 1.0 | Source baseline: zahlen_deploy_0616A.tar.gz | June 2026

‌Chapter 16 - SDK Examples

The examples in this chapter are intentionally small enough to understand and strong enough to become the foundation of a production client. They use environment variables for secrets, JSON request bodies, explicit timeouts, and stable identifiers.

1. ‌Common environment variables




   export ZAHLEN_BASE_URL="https://api.example.com"

   export ZAHLEN_API_KEY="zk_live_REPLACE_ME"

• Use a secret manager or protected runtime environment for ZAHLEN_API_KEY.

• Use separate base URLs and keys for development, staging, and production.

• Never expose the key in browser code, a mobile binary, source control, screenshots, or support tickets.

1. ‌curl examples

   curl is useful for connectivity tests, smoke tests, and reproducing an integration issue. Use -sS for clean output and --fail-with-body when available so error bodies remain visible.

   ‌Health and version




   curl -sS "$ZAHLEN_BASE_URL/v1/health" | python -m json.tool




   curl -sS "$ZAHLEN_BASE_URL/v1/version" | python -m json.tool

‌Submit a payment event

‌Request a next-generation retry decision

1. ‌More curl workflow examples

   ‌Retrieve an event and its decision




   EVENT_ID="evt_20260616_0001"




   curl --fail-with-body -sS \

   -H "X-API-Key: $ZAHLEN_API_KEY" \

   "$ZAHLEN_BASE_URL/v1/payment-events/$EVENT_ID" | python -m json.tool




   curl --fail-with-body -sS \

   -H "X-API-Key: $ZAHLEN_API_KEY" \

   "$ZAHLEN_BASE_URL/v1/payment-events/$EVENT_ID/decision" | python -m json.tool

‌Report a retry outcome

from future import annotations

import os

from typing import Any import requests

BASE_URL = os.environ["ZAHLEN_BASE_URL"].rstrip("/") API_KEY = os.environ["ZAHLEN_API_KEY"]

class ZahlenClient:

def init (self, base_url: str = BASE_URL, api_key: str = API_KEY) -> None: self.base_url = base_url.rstrip("/")

self.session = requests.Session() self.session.headers.update({

"X-API-Key": api_key,

"Content-Type": "application/json",

})

def request(self, method: str, path: str, *, json: dict[str, Any] | None = None, idempotency_key: str | None = None) -> dict[str, Any]:

headers = {}

if idempotency_key:

headers["Idempotency-Key"] = idempotency_key response = self.session.request(

method, f"{self.base_url}{path}", json=json, headers=headers, timeout=(5, 25),

)

response.raise_for_status() return response.json()

1. ‌Python client foundation




   The connect/read timeout tuple prevents a process from waiting indefinitely. Production clients should also map HTTP errors into application-specific exceptions and capture safe request correlation metadata.

2. ‌Python core workflow

   client = ZahlenClient()




   ingest = client.request("POST", "/v1/payment-events", json={ "source": "billing_platform",

   "events": [{

   "event_id": "evt_20260616_0001", "decline_code": "51",

   "issuer_bin": "411111",

   "amount_minor": 2999, "currency": "USD", "attempt_number": 1,

   }],

   })

   print("upload_job_id:", ingest["upload_job_id"])




   decision = client.request( "POST",

   "/v1/_next/retry-decision", json={

   "attempt_number": 2,

   "decline_code": "51",

   "issuer_bin": "411111",

   "amount_minor": 2999, "currency": "USD",

   },

   idempotency_key="order-8842-attempt-2",

   )

   print("decision:", decision.get("decision"))




   outcome = client.request( "POST",

   "/v1/retry-outcome", json={

   "attempt_number": 2, "outcome": "APPROVED",

   "request_id": decision.get("request_id"), "decision_id": decision.get("decision_id"), "settled_amount_minor": 2999, "currency": "USD",

   },

   idempotency_key="outcome-order-8842-attempt-2",

   )

   print("outcome_id:", outcome.get("outcome_id"))




   Preserve the identifier chain

   Store event_id, batch_id or payment_event_batch_id, upload_job_id, request_id, decision_id, and outcome_id. These values connect merchant logs, Zahlen audit records, and investigation workflows.

3. ‌Python error handling




   import time import random import requests




   def call_with_backoff(call, max_attempts: int = 5): for attempt in range(max_attempts):

   try:

   return call()

   except requests.HTTPError as exc:

   status = exc.response.status_code

   if status in {400, 401, 403, 404, 409, 422}:

   raise

   if status not in {429, 500, 503} or attempt == max_attempts - 1: raise

   retry_after = exc.response.headers.get("Retry-After")

   delay = float(retry_after) if retry_after else min(30, 2 ** attempt) time.sleep(delay * random.uniform(0.75, 1.25))

   except (requests.Timeout, requests.ConnectionError): if attempt == max_attempts - 1:

   raise

   time.sleep(min(30, 2 ** attempt) * random.uniform(0.75, 1.25))

1. ‌JavaScript client foundation




   const BASE_URL = process.env.ZAHLEN_BASE_URL.replace(/\/$/, ""); const API_KEY = process.env.ZAHLEN_API_KEY;




   async function zahlenRequest(path, options = {}) { const controller = new AbortController();

   const timer = setTimeout(() => controller.abort(), 25000); try {

   const response = await fetch(`${BASE_URL}${path}`, {

   ...options,

   signal: controller.signal, headers: {

   "Content-Type": "application/json", "X-API-Key": API_KEY,

   ...(options.headers || {})

   }

   });

   const body = await response.json().catch(() => ({})); if (!response.ok) {

   const error = new Error(`Zahlen HTTP ${response.status}`); error.status = response.status;

   error.body = body; throw error;

   }

   return body;

   } finally { clearTimeout(timer);

   }

   }

1. ‌JavaScript core workflow

   const ingest = await zahlenRequest("/v1/payment-events", { method: "POST",

   body: JSON.stringify({ source: "billing_platform", events: [{

   event_id: "evt_20260616_0001", decline_code: "51",

   issuer_bin: "411111",

   amount_minor: 2999, currency: "USD", attempt_number: 1

   }]

   })

   });

   console.log(ingest.upload_job_id);




   const decision = await zahlenRequest("/v1/_next/retry-decision", { method: "POST",

   headers: {"Idempotency-Key": "order-8842-attempt-2"}, body: JSON.stringify({

   attempt_number: 2,

   decline_code: "51",

   issuer_bin: "411111",

   amount_minor: 2999, currency: "USD"

   })

   });

   console.log(decision);




   const outcome = await zahlenRequest("/v1/retry-outcome", { method: "POST",

   headers: {"Idempotency-Key": "outcome-order-8842-attempt-2"}, body: JSON.stringify({

   attempt_number: 2, outcome: "APPROVED",

   request_id: decision.request_id, decision_id: decision.decision_id, settled_amount_minor: 2999, currency: "USD"

   })

   });

   console.log(outcome.outcome_id);

2. ‌Typed-client checklist

   • Reject unknown request fields before transmission, matching Zahlen strict models.

   • Represent nullable response fields explicitly rather than assuming every enrichment exists.

   • Keep decimal amount fields separate from integer amount_minor and settled_amount_minor fields.

   • Centralize authentication, timeouts, status mapping, retry budgets, and structured logging.

   • Use unique event IDs and stable idempotency keys for one logical operation.

   • Capture server request IDs and durable object identifiers in logs without exposing secrets.

   • Test 401, 403, 404, 409, 422, 429, 500, 503, timeout, and uncertain-write scenarios.

3. ‌Production readiness checklist
